Product Detail

Model No.: GST100

Production Capacity: 15

Delivery Date: 30 days

Brand Name: GST

Frequency: 50/60

Rated Voltage: 400V

Means of Transport: Ocean

Packing: wooden cases

Output Type: AC Three Phase

Speed: 1500/1800

Rated Power: 100

100KVA SILENT TYPE DIESEL GENERATOR SET: 100KW

100KVA SILENT TYPE

TECHNICAL DATA
DIESEL ENGINE MODEL	6BT5.9-G2	6BTA5.9-G2	6BTAA5.9-G2
Engine Characters	Water-Cooled,inline,4cycle,6-cylinders,direct injection ,Wet cyling linder,1500rpm
Constant output (kW/kVA)	88/110	110/137	123.2/154
Standby Output (kW/kVA)	96.8/121	120/150	135.5/169.4
Aspiration	Turbocharged	Turbocharged	Turbocharged
Bore(mm) X Stoke(mm)	102x120	102x120	102x120
Cubic Capacity (Liters)	5.9	5.9	5.9
Piston Speed (m/s)	6	6	6
Compression Ratio	16.5:1	16.8:1	16.5:1
Machine Governor	≤6%	≤6%	≤6%
Electronic Governor	≤1%	≤1%	≤1%
Acostic Pressure(dBA)	95	90	95
Exhaust Temperature	577	562	481
Lube Capacity	16.4	16.4	16.4
Cooling System Voluem	11L	11L	11L
Combustion Air Flow	5.8m3/min	7.8m3/min	14.3m3/min
Exhaust Gas Flow	5.88m3/min	5.88m3/min	5.9m3/min
Rating Fuel Consumption (L/h)	23.1	27.5	32.2
ALTERNATOR MODEL	UCI 274C	UCI 274D	UCI 274E
Continuous Output (kW/kVA)	80/100	96/120	112/140
Power Efficiency	94.1%		91.6%
Voltage Regulation	≤±1%	≤±1%	≤±1%
Excitation Type	Brushless	Brushless	Brushless
Insulation Class	H	H	H
DIMENSIONS AND WEIGHTS
MODEL OPEN&SOUNPROOF	GST80C/S	GST96C/S	GST112C/S
Approximate Length	2300/3200mm	2450/3450mm	2550/3450mm
Approximate Width	830/1300mm	950/1350mm	950/1350mm
Approximate Height	1450/1900mm	1650/1900mm	1650/1900mm
Approximate Gross Weight	1360/2100kg	1400/2180kg	1600/2285kg
Technical data subject to change without previous notice.
